System Technik

Double Side Coater
DSC 200 MUV

This spin coating machine is a manually handled system for hard coating of both sides (concave/convex) of organic ophtalmic lenses.

Manual cleaning before coating suffices and operating the system is very simple.

The standard spin coating system DSC 200 MUV has a high energy UV bulb for curing. An oven for thermo curing is optionally available.

Servicing and maintenance is almost zero. There are no electronics in the machine which makes it an excellent choice for developing countries. The units can be turned off when they are not needed.

In combination with a laminar flowbox (optional) an expensive clean room is not necessary. Additionally with certain lacquers no air conditioning is needed.

All these features make investment and running costs very low.

Conception and production in Germany guarantees high quality and good service.

For more information please contact System Technik.

Specifications

General Coating: approx. 30–40s (after lens cleaning) UV Curing Time: 30–45s (one-sided) Power range: Concave -12.00 and more Convex 9.00 and more Compressed air pressure: 50–80ψ Lens diameter: 40–85mm Turning speed: 50–1200rpm

Electrical power Spin unit: 240V at 5A (110V on request) UV Curing unit: 380V/440V at 12A (three phase, 240V on request)

Weight and dimensions

	L	W	H	Weight
Spin unit	58cm	77cm	160cm	approx. 80 kg
Control unit	58cm	58cm	154cm	approx. 60 kg
